Multi Security Confirmation Bluetooth Wallet Card ISO7816 F05 F08 Chip
Product Details:
| Place of Origin: | Shenzhen, China |
| Brand Name: | HY |
| Certification: | RoHS authentication/CB authentication |
| Model Number: | A082 |
Payment & Shipping Terms:
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Single transparent bag, outer carton |
| Delivery Time: | 10-15 working days |
| Payment Terms: | T/T |
| Supply Ability: | 20000PCS |
|
Detail Information |
|||
| Encapsulation Material: | PVC PETG （ Optional Option ） | Product Type: | ISO7816 （ Optional Option ） |
|---|---|---|---|
| Application Range: | Finance, Trade, Travel, Transportation, Telecommunications, Medical | Card Body Shape: | Customizable |
| Security Chip: | F05 / F08 Guest Designated | Confirmation Module: | Buttons / Fingerprints (Customizable) |
| High Light: | ISO7816 Bluetooth Wallet Card,F05 Bluetooth Wallet Card,ISO7816 ble card |
||
Product Description
Multi Security Confirmation Bluetooth Wallet Card ISO7816 F05 F08 Chip
Encrypted monetary wallet Bluetooth smart card multi security confirmation
Product Background: With the rapid development of technology, the public payment method has changed, especially the arrival of the epidemic, has accelerated the digital transformation of the payment. In this process, digital currency should be born. In 2020, it began to enter the public's sight. The market has shown different hardware vectors, such as mobile phones, financial recipients, mobile phones with SE security components. Its most common carrier, financial visual card, is also a visible bank card; existing products in the pilot are mainly in contactless passive video, mainly applied to small-free payment, user groups in old age People scenes are many. Bluetooth Wallet Card
| Product parameters | Type | Active / passive |
| Card body shape | Customizable | |
| Screen | Electronic Paper / Glass / OLED screen | |
| Screen size | 1.02 inch / 1.54 inch Section screen / dot screen | |
| Appearance color | GS Pantone chromatography shall prevail | |
| Thumbprint module | IDEX/FPC | |
| Beacon tips | Led prompt light [red, green] | |
| Interface | M7816 interface (optional) | |
| RFID | 13.56mhz | |
| NFC | Optional | |
| Bluetooth | Optional | |
| Waterproof grade | IP68 industrial waterproof | |
| Number of keys | 5 bits / 13 bits (optional) | |
| Ultra thin lithium battery | >80mah (as required) | |
| Charging mode | Magnetic suction / wireless charging / solar charging |
Smart card cold pressure process: Package PCBA into a smart card form, has always been a technical difficulty of smart card industry, and the high temperature of traditional processes will lead to problems such as lithium batteries, component damage, etc., and jointly establish a special research team in 2014. The PCBA seal technology, through continuous research, developed related technologies and equipment for the PCBA seal, and corresponding glue formulas, successfully achieved ultra-thin lithium batteries, chips, solar panels, fingerprints, ink screens or other components or The module is encapsulated in normal temperature, high-end smart card with high performance, high reliability, appearance, and bending test. At present, it can reach 20000-30000PCS at present, and under the continuous efforts, production capacity, process, performance is gradually improved and improved.
Module function
1. Electronic ink screen , information display and confirmation of account number during payment.
2. NFC module , realize "touch and touch collection and payment" and "double offline payment" between cards.
3. Bluetooth module , connect with mobile phone to realize information synchronization. In addition, the card is also equivalent to ukey security cipher we usually use.
4. Wireless charging , magnetic suction charging , multi-functional charging mode, more convenient for users.
5. Digital keys (mechanical / touch keys) , the necessary functions of multi-function cards, the input way of passwords and amounts.
6. Se security chip , encryption algorithm, ensuring payment security and difficult to crack.
7. Ultra thin lithium battery , non-contact card, power source, solid-state safety lithium battery.
