Responsive Security Fingerprint Smart Cards Ultra Long Battery Life
Product Details:
| Place of Origin: | Shenzhen, China |
| Brand Name: | HY |
| Certification: | RoHS authentication/CB authentication |
| Model Number: | B0020 |
Payment & Shipping Terms:
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Single transparent bag, outer carton |
| Delivery Time: | 10-15 working days |
| Payment Terms: | T/T |
| Supply Ability: | 20000PCS |
|
Detail Information |
|||
| Craft: | Cold Pressure Process | Charging Mode: | Magnetic Suction, Wireless Charging, Solar Charging |
|---|---|---|---|
| PCBA: | Use Flexible FPC Material | Layout Color: | GS Pantone Chromatography Shall Prevail |
| Hardware Design: | Schematic Diagram And PCB File Drawing | Rewire: | Optical Erasable Life Of Over 1 Million Times |
| High Light: | Responsive Fingerprint Smart Cards,flexible FPC Fingerprint Smart Cards,1.02 inch fingerprint payment card |
||
Product Description
Fingerprint Smart Card: Ultra-long Battery Life, Responsive Fingerprint Security Smart Card
Fingerprint Smart Card Introduction:
The fingerprint smart card adopts the self-developed glue and cold-pressing sealing process, which breaks the traditional hot-pressing. The circuit board PCB is embedded in the card, and the thin battery, Bluetooth iBEACON module, fingerprint module, blockchain, switch and other components are packaged. Small fingerprint smart cards with big functions. The ultra-thin card body will not cause the battery life to be too short due to the small battery capacity. On the contrary, it can obtain a long battery life with its own low power consumption, and it can be used for up to half a year to a year without charging.
|
Fingerprint Smart |
Fingerprint Smart Card Type | Active / passive |
| Screen | Electronic Paper / Glass / OLED screen | |
| Screen size | 1.02 inch / 1.54 inch Section screen / dot screen | |
| Appearance color | Customizable layout | |
| Thumbprint module | IDEX/FPC | |
| Beacon tips | Led prompt light [red, green] | |
| Interface | 7816 interface (optional) | |
| RFID | 13.56mhz | |
| NFC | Optional | |
| Bluetooth | Optional | |
| Waterproof grade | IP68 industrial waterproof | |
| Number of keys | 5 bits , 13 bits(Customizable) | |
| Ultra thin lithium battery | >80mah (as required) | |
| Charging mode | Magnetic suction / wireless charging / solar charging |
Fingerprint Smart Card Technical Process Description:
Packaging PCBA into smart card form has been a technical difficulty in the smart card industry for many years. The high temperature of traditional process will lead to lithium battery failure, component damage and other problems. Heyang technology began to establish a special scientific research team in 2014 to tackle PCBA card sealing technology through continuous research, We have developed relevant technologies and equipment for PCBA card sealing and corresponding glue formula, and successfully encapsulated ultra-thin lithium batteries, chips, solar panels, fingerprints, ink screens and other components or modules into high-end smart cards with high performance, high reliability, flat appearance and bending test standards at room temperature. At present, the daily production capacity reaches 20000-30000 PCs. with the continuous efforts of Heyang, The production capacity, process and performance are gradually improved and improved.
Fingerprint Smart Card Application:
Widely used in prison management systems, security systems, financial systems, personnel positioning systems, new generation campus card systems, urban traffic cards and other occasions.
