13.56 Mhz RFID Contactless Card PVC Embedded Smart Card 0.84-3.0mm thickness
Product Details:
| Place of Origin: | Shenzhen, China |
| Brand Name: | HY |
| Certification: | RoHs authentication CB authentication |
| Model Number: | B0040 |
Payment & Shipping Terms:
| Minimum Order Quantity: | Negotiable |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Single transparent bag, outer carton |
| Delivery Time: | 10-15 working days |
| Payment Terms: | T/T |
| Supply Ability: | 20000PCS |
|
Detail Information |
|||
| Size: | L*W(mm)=85.6*53.98 | Thickness: | 0.76-2.2mm |
|---|---|---|---|
| Agreement: | ISO7816 | Erasable Number Of Times: | ≥10 Billion Times |
| Working Frequency: | 13.56mHz | Chip: | SE(customized) |
| High Light: | 13.56 Mhz RFID Contactless Card,PVC RFID Contactless Card,RFID embedded smart card |
||
Product Description
13.56 Mhz Rfid Card RFID chip embedded smart card Rfid Contactless Card
RFID ID Cards Quick details:
1. Supply the world
2. Material: PVC
3. Experts/factories/manufacturers
4. Consumption/shopping/one-card
5. Color: White/black/blue (customizable)
Nfc Read Rfid Card Product Introduction: The RFID embedded smart card developed by Heyang Technology can realize shopping consumption, access control, attendance, positioning and other functions without any physical contact with the card reader. Using independently developed glue and cold pressing technology, the thickness of the card is customized at 0.84-3.0mm, and the appearance thickness is the same as that of ordinary bank cards. It can realize the function of ink screen information display, fingerprint operation and multiple password keys operation. The product can use low power consumption built-in lithium battery scheme, realize solar charging, wireless charging, magnetic charging and other ways to choose.
Rfid Contactless Card Parameter table:
| Product parameters | Product name | Ble Id Card |
| Type | Active | |
| Appearance color | Blue(customized) | |
| Anti card loss thickness | 0.76-2.2mm | |
| Card of body size | L*W(mm)=85.6*53.98 | |
| Chip | SE(customized) | |
| RFID | 13.56mhz | |
| NFC | Optional | |
| Bluetooth | Optional | |
| Waterproof grade | IP68 industrial waterproof | |
| Encapsulation material | PVC ABS PET PETG | |
| Data storage period | 100 years | |
| Number of keys | 1-13 bits(customized) | |
| Storage | 128K bit (customizable) | |
| Ultra thin lithium battery | >80mah (as required) | |
| Charging mode | Magnetic suction / wireless charging / solar charging |
Rfid Pvc Card FAQ:
1. Q: Are you a factory or trading company?
A:We are a factory.
2. Q: Can we costomize the size, color, logo and package of the product?
A: Yes, all of these can be cusomized according to your needs.
3.Q:What is the cooperation model like?
A: The customer provides the main components and design schematic diagram. Our company is responsible for PCBA optimization design, main / auxiliary material supply chain recommendation, overall cost budget, PCBA card sealing, and final finished PCBA smart card shipment.
B: The customer has PCBA circuit board and supporting materials. Our company is responsible for PCBA card packaging, electrical performance, reliability and other tests, and the final finished PCBA smart card is shipped.
C: The design idea is provided by the customer, and our company provides a variety of scheme design suggestions. After reaching an agreement, the design and production are carried out, and the final finished PCBA smart card is shipped.
